Small and medium flow of Irrigation systems in greenhouses,
small/medium farm fields
Strongly built Nylon resins body enables resistance for
high pressure
Long lasting and strong designed in Closure system
Wide range of flow rates
High quality raw materials of disc elements resulted in fine
filtration
Perfect pressure sealing at low and high pressures
Easy to install/remove/maintain and simple expansion of
existing system
Long-term operation with little maintenance or cleaning
Maximum cost efficiency
|
 |
|
 |
|
Inlet/ Outlet Diameter |
Flow Rate (max) |
Working Pressure (max) |
Disc outside Diameter |
Element Length |
Filtration Degree |
Weight (net) |
Materials |
1.5" (40 mm) |
15 m©ø/h |
8 bar |
65 mm |
230 mm |
120 mesh |
1.5kg |
Housing & Disc : Nylon Resins Seals : Nitrilo Rubber |
2" (50 mm) |
25 m©ø/h |
8 bar |
130 mm |
248 mm |
120 mesh |
6kg |
3" (75 mm) |
45 m©ø/h |
8 bar |
130 mm |
496 mm |
120 mesh |
10kg |
|
|
 |
|
|
|
|
